DOBOT CR16A
DOBOT CR16A
Price range: €23.899,00 through €34.279,00excl. VAT
The DOBOT CR12A has a payload limit of up to 12 kg, opening up a wider range of applications for collaborative robots. With a working radius of 1200 mm, the CR12A can meet the demands of heavy-duty picking, packing, palletizing and welding in the automotive, home appliance, logistics and metalworking industries.
Performance
Safety
Scalability
Flexibility
Building upon the safety, efficiency, flexibility, and ease of use of the CR series, the CR16A breaks through the payload limit to 16kg, opening up a wider range of applications for collaborative robots. With a 1000 mm working radius, the CR16A can meet the demands of heavy-duty picking, packing, palletizing and welding in the automotive, home appliances, logistics and metal processing industries.
The CR16A adopts an industry-first dual-channel end effector design, which can directly connect to multiple end tools. It also features a visual status indicator at the base for intuitive recognition of operating status.
The CR16A has a working radius of 1000 mm and a maximum payload of 16 kg. With advanced motion control algorithm, the CR16A operates more stably, with residual vibrations reduced by 50% during high-speed emergency stops.
The CR16A supports Profinet and Ethernet/IP communication protocols and connects seamlessly with PLC. It has 24 digital IO ports with industry leading support for PNP and NPN switching to expand applications with ease.
The robot body and control box both achieve a high protection level of IP54. When overloaded, the robot will automatically sound an alarm. The CR16A also features an innovative electromagnetic brake protection, which reduces the end tool drop distance at power failure.
The DOBOT CR16A has a payload limit of up to 16 kg, opening up a wider range of applications for collaborative robots. With a working radius of 1000 mm, the CR16A can meet the demands of heavy-duty picking, packing, palletizing and welding in the automotive, home appliance, logistics and metalworking industries.
| Weight | 40 kg |
|---|---|
| Edition | AC Edition (Standard), DC Edition (Mobile) |
| Warranty | 1-year warranty service, 2-year warranty service, 3-years warranty service, 4-years warranty service, 5-years warranty service |
