EWELLIX DOBOT CR Series LIFTKIT

  • Product price: €6.999,00excl. VAT

    EWELLIX DOBOT CR Series LIFTKIT

    Vertical axis for all collaborative robots LIFTKIT-DB-900

    Compatible with DOBOT CR10, CR12, CR16

    • Linear axis for collaborative robots LIFTKIT-DB-900

    Cobots are often used for palletizing, but they reach their limit as soon as the pallet stack reaches a certain height.

    The easy-to-assemble LIFTKIT extends the range of the cobot by moving it along a vertical axis.
    The base of the Cobot can be raised or lowered during palletizing so that it is always in an optimal working position. This extended reach improves productivity and reduces costs.

    Ewellix LIFTKIT is a turnkey system and includes a lifting column with a cobot mounting interface, a controller and a software plug-in for compatible robots so that movements can be programmed directly via the cobot controller.

    Advantages:

    • Extend the working range of the cobot to increase productivity and save costs
    • No hardware/software upgrades required
    • Direct positioning access within the cobot operating environment (if available)
    • Flicker-free movement
    • High positioning accuracy

    Features:

    • Certified UR and Omron positioning axis
    • Turnkey complete system
    • Robust column design for industrial use
    • Silent operation
    • High stiffness

    Operating range extension

    • Vertical lifting of the cobot by up to 1 400 mm with compact retracted height
    • Robust column design for industrial use, vibration free motion and virtually maintenance free

    Plug-and-play solution

    • Hardware interface compatible with any robots
    • LIFTKIT control through TCP/IP

    Cost savings and higher productivity

    Cobots in combination with Ewellix LIFTKIT offer a cost-effective solution to upgrade an existing assembly workshop from a manual to a fully automated line.

    The lift kit is suitable for the CR10, CR12 and CR16 and is compatible with Dobot palletizing software StudioPRO.

    LIFTKIT version for ceiling mounting available on request.

    Stroke up to 1 400 mm on request.

    Specifications

  • Specificaties

    Column type
    TLT

  • Performance Data

    Max. Push load
    1500N
    Max. Pull load
    0N
    Max. dynamic moment
    210 Nm
    Max. static moment
    3 000 Nm
    Max. linear speed
    80 mm/s
    Duty cycle
    10% (20% at 500N)

  • Mechanical Data

    Screw type -
    Acme screw
    Stroke range
    500 - 1 400 mm
    Retracted length (software controlled)
    Stroke/2 + 275 mm
    Weight @ 0 mm stroke
    21 kg
    Δ weight per 500 mm stroke
    1,7 kg
    Robots compatibility
    Any
    Cable management
    Threads on column and interface plate to attach cable management

  • Electrical

    Input Voltage/Current
    120 VAC / 6,5 A
    230 VAC / 3,3 A
    Input frequency Hz
    50-60 Hz
    Input Fuse
    10A
    I/O voltage
    24 VDC
    I/O current
    max. 10 A not protected
    Emergency stop
    STO up to PLe, Cat.4

  • Communication

    Control interface
    TCP/IP
    Positioning, repeatability
    ± 1 mm
    Accessible positions
    any
    Feedback
    Position & Status
    Soft start and stop
    Implemented for smooth operation

  • Environment

    Environment Type of protection
    IP40
    Ambient temperature
    +10 to +40 °C
    Max. humidity
    85 %
    Vibration
    Stationary industrial environment

  • Shipping List

    Quick start guide
    Controller
    Raspberry Pi controller
    Lifting column
    Bottom fixation plate
    Mounting plate DOBOT CR10
    Handswitch Controller
    I/O cable
    RS232 cable
    Ethernet cable
Request quotation
