• DH-Robotics PGC Series

    DH-Robotics PGC Series of collaborative parallel electric grippers is an electric gripper mainly used with collaborative robots. It has the advantages of high protection level, plug and play and can withstand a heavy payload. The PGC Series combines precision force control and industrial aesthetics and won the Red Dot Design Award and iF Design Award in 2021.

    Product Features

    • Plug and play: PGC series supports plug & play with most collaborative robot brands on the market which is easier to control and program.
    • Smart feedback: Using real-time data.
    • High payload: The gripping force of the PGC series could reach 300 N, and the maximum load can reach 6 kg, which can meet more diverse gripping needs.
    • High protection level: The protection level of PGC series is up to IP67, so it can work under harsh conditions such as machine tending environment.
  • PGC-50-35

    Gripping Force (per jaw)
    15~50 N
    Stroke
    37 mm
    Recommended Maximum Payload
    1 kg
    Opening/Closing Time
    0.7 s/0.7 s
    Position Accuracy
    ± 0.03 mm
    Noise Emission
    < 50 dB
    Product Weight
    0.5 kg
    Driving Method
    Precision planetary reducer + Rack and pinion
    Size
    124 mm x 63 mm x 63 mm
    Communication Interface
    Standard:Modbus RTU (RS485), Digital I/O Optional:TCP/IP, USB2.0, CAN2.0A, PROFINET, EtherCAT
    Rated Voltage
    24 V DC ± 10%
    Rated Current
    0.25 A
    Peak Current
    0.5 A
    IP Rating
    IP 54
    Recommended Environment
    0~40°C, below 85% RH
    Certifications
    CE,FCC,RoHS
  • PGC-140-50

    Gripping Force (per jaw)
    40~140 N
    Stroke
    50 mm
    Recommended Maximum Payload
    3 kg
    Opening/Closing Time
    0.6 s/0.6 s
    Position Accuracy
    ± 0.03 mm
    Noise Emission
    < 50 dB
    Product Weight
    1 kg
    Driving Method
    Precision planetary reducer + Rack and pinion
    Size
    138.5 mm x 75 mm x 75 mm
    Communication Interface
    Standard:Modbus RTU (RS485), Digital I/O Optional:TCP/IP, USB2.0, CAN2.0A, PROFINET, EtherCAT
    Rated Voltage
    24 V DC ± 10%
    Rated Current
    0.4 A
    Peak Current
    1 A
    IP Rating
    IP 67
    Recommended Environment
    0~40°C, below 85% RH
    Certifications
    CE,FCC,RoHS
  • PGC-300-60

    Gripping Force (per jaw)
    80~300 N
    Stroke
    60 mm
    Recommended Maximum Payload
    6 kg
    Opening/Closing Time
    0.8 s/0.8 s
    Position Accuracy
    ± 0.03 mm
    Noise Emission
    < 50 dB
    Product Weight
    1.5 kg
    Driving Method
    Precision planetary reducer + Rack and pinion
    Size
    178 mm x 90 mm x 90 mm
    Communication Interface
    Standard:Modbus RTU (RS485), Digital I/O Optional:TCP/IP, USB2.0, CAN2.0A, PROFINET, EtherCAT
    Rated Voltage
    24 V DC ± 10%
    Rated Current
    0.4 A
    Peak Current
    2 A
    IP Rating
    IP 67
    Recommended Environment
    0~40°C, below 85% RH
    Certifications
    CE,FCC,RoHS
Request quotation
